Saturday, December 31, 2011

Tamron 10-24mm F/3.5-4.5 Review.











Lens: Tamron 10-24mm Di II F/3.5-4.5 @ 10mm, F/3.5, 30.00, ISO800


First of all, many thanks to Nordic Digital for providing the lens to find out how it performs.


Previous 8 photos posted here using separate posts are all taken with this lens.


Official web site of Tamron 10-24mm F/3.5-4.5


What could be the reasons to have this Tamron lens? I know at least 3: It is really wide, 10mm. It is a lightweight lens, not a 3kg training module. Finally, if won't cost you an arm and the leg, to get it. So is it all worth it? Let's see.






OOTB, Build Quality.


This is a DX lens, so for small sensor cameras. Nikon D90 Crop factor is 1,5, so the lens acts as a 15-36mm equivalent. The body is all plastic - not bad at all; however I'd wish the lens to be heavier - why not even larger. So the build quality is a mixed bag - it should last a couple of years of heavy use, or a couple of hundred of years with little or no use. As always, front & rear caps are included, as well as the lens hood. The filter thread is 77mm - be sure you use special thin filters or the edges are visible - the view angle is just so wide at 10mm.


This is a regular wide angle lens, not a fisheye. Fisheye generally means the center area of the lens are "stretched out" so it magnifies the area at the center more than the corners. A fisheye lens can be narrower than a true wide angle lens despite the effect of "very wide" with fish eye lens. The best wide angle lens are fixed focus lens, as opposed to zoom ones. This Tamron is essentially a zoom lens, so with loads of potential to pay interest to picture quality with having the advantage of using zoom.






Focus, Auto Focus.


Unlike the extreme long focal length Tamron 180mm Macro F/3.5 I was able to use recently, the 10-24mm is another universe. If you stop down the lens and forget about the focus, majority of the images are in focus anyway. It is just so darn wide. The lens is however able to focus as close as 35cm. This separates the subject from the background nicely enough. Nothing to analyze about the bokeh, the only scenario we can talk about it at all, is the closest focus at wide open through the zoom range, and in this case the bokeh was OK, however the scenario described was actual at less than 1% of the time.






The Good and the Bad.


Let's start with the bad. First of all the CA (Chromatic Aberration) of the lens is extremely bad. Majority of the situations you have a high contrast area, the heavy CA is there. It is better at the center, but the corners remain horrible even when stopped down to F/8. Several times I found myself using black and white editions of the pictures just because of I was tired of fighting with the CA-monster.


The sharpness of the lens could also be better. As we know Tamron IS able to make sharp lens, so I hope to see them to improve the sharpness of this lens as well. With that said, the contrast of the glass also was not exactly what I was expecting.


Another issue (could be a specific regarding to what kind of body was used) was that the camera (Nikon D90) was not able to meter the optimal exposure. The wider the viewing angle, the less the chance to get properly exposed images. So I ended up with using the manual mode at 90% of the time - (M is actually my favorite mode).


Now the good. As expected, the viewing angle is very wide. For me it is a single reason to buy this lens - a true 15mm wide angle (10mm x1,5). The sweetest spot seems to be classical F/7.1 & F/8. This is where your images are relatively sharp, relatively contrasty and in the center there's almost zero CA visible. The (light) weight of the lens is also a + if you are heavily loaded with equipment.






Final word.


Considering the price tag (New around €450 in EU, $450 in US) the package is not bad. It is a consumer oriented lens not offering the best picture quality, but offering a very wide angle to take pictures at (16mm for Canon DX-s, 15mm for Nikons, Sony's and Pentax'es). For the first wide angle lens it could be a nice choice. You could also might want to consider Sigma's 10-20mm DX lens instead.


So if you do not mind the issues listed above, go try it and buy it - it is lovely to use at its sweet spot at 10mm.

Snowshine


Lens: Tamron 10-24mm Di II, F/7.1, 1/50, ISO200

Sunshine


Lens: Tamron 10-24mm Di II F/3.5-4.5 @ 10mm, F/3.5, 1/30, ISO200

Once Upon a Time

Lens: Tamron 10-24mm F/3.5-4.5

Hangar

Lens: Tamron 10-24mm Di II F/3.5-4.5 @ 10mm, F/7.1, 1/30, ISO200

Force Majeure

Lens: Tamron 10-24mm Di II F/3.5-4.5 @ 10mm, F/7.1, 1/50, ISO200

Desolation


Lens: Tamron 10-24mm Di II F/3.5-4.5 @ 10mm, F/8, 1/200, ISO400

Dry Land


Lens: Tamron 10-24mm Di II F/3.5-4.5 @ 10mm, F/8, 1/50, ISO200

Ristna.


Lens: Tamron 10-24mm Di II F/3.5-4.5 @ 10mm, F/8, 1/250, ISO200

Saturday, December 24, 2011

Pictures from Ristna, Hiiumaa




Ristna is the west point of Hiiumaa. If waves are large somewhere in Estonia, this is here - it is an opened Baltic Sea and it gets deep quite quickly.



The weather was unpredictable this weekend. It could snow inland (+1), it could rain here and there, it could also be sunny a bit. However it was quite warm (+5C) in Ristna Tip, and it was raining and sunny at the same time. Rainbow in a horizon - not something anyone would expect in winter in this latitude of earth.



The waves could easily reach 2 meters high - a surfer's paradise.

The multi-directional low horizon light made the  color of the water admirable, so unusual to the nature of the Baltic Sea.

It is the sky drama that often  catches out attention - with no megapixel limit and real world, truly a 5D cinema indeed.

Saturday, November 26, 2011

Lens Sharpness

A nice reading about if your lens (glass) is sharp, or is it anything else?


Article at dpreview by Roger Cicala (lensrentals.com)


Long story short, it is not only glass that makes your lens sharp. It is also the body of the lens, the precision of engineering of lens and also body; also (auto) focus errors, calibration issues. This also goes for the pricier part of the lens selection.


Once I used to try out used "old built like a tank" Nikkor lens. I thought the less used the lens the better the picture. Guess what? The major logic was, the more worn the lens, the better the picture. I was even able to find Nikkor 50mm 1:1.4AI lens with the edges of diaphragm so worn out that I was thinking I was sent broken lens. The reality was, the lens was that sharp and contrasty that the users through all time had understood it well and therefore the lens was also used a lot. I'm using the same lens today and it still outperforms any current and past 50mm primes, including the ones with premium price.


A nice though at the end of the article: "Trying to find exactly the sharpest copy of the sharpest lens is a fool’s errand: you’ll be looking for something that doesn’t exist"


Of course the sharpest copy actually exists, it is just that you don't have the time and possibilities to find it, nor there is any reasonable reason to do it; and it is also true that the perfect engineering just does not exist (with given budget).

Wednesday, November 23, 2011

Lytro Light Field Camera - Innovation of the Year

A couple of weeks ago, Californian based technology company Lytro announced it has its first product ready - a Lytro Light Field Camera. We know Sony has made an extremely cool electronic viewfinder this year. Sigma has announced the successor of its Foveon sensor. Retro trends are hitting the market with Fujifilm X100 and Nikon V1/J1. Canon is starting to compete with Red. So what's so special about Lytro?






Isn't it another geek toy with ultra small sensor and crappy lens? Well, since the product will be sold starting February 2012, we don't know the truth, but..


What we know is, that the camera concept redefines "camera" far more in a new way anyone could think of, so far. If you didn't know it is a camera, what would you think it would be? Perhaps something cool from Apple.. Maybe a lipstick with LCD screen showing the percentage of stick remaining? All wrong. It is the camera with Light Field Technology - mainly meaning you can choose the focus after you have take the picture. Magic.


How unconventional is the camera body design. How simple is the layout of the unit. How innovative is the technology. If you take a look at any considerable camera shop online, you can find some 300+ camera models on sale. From $40 to $40,000. Every single of it is a conventional camera - as we today know it. But one - the new Lycro. Let's see about if the fairy tale becomes true, in a couple of months already.


You can read thoughts from the CEO of Lytro, Ren Ng, here; you can also experience here how does it work to select focus point after the picture is taken.

Tuesday, November 08, 2011

Tamron 180mm F:3.5 Macro 1:1 Review

First of all, thank you Nordic Digital for providing such a great lens for to try out how it performs in track and field.










The lens was announced in 2003 already, still in production as of 2011, official web site of Tamron for this lens. In a word it is a high quality lens, Tamron is proud to name it "High-Class Tele Macro" which the clarity and sharpness of the glass definitely deserves. This short review does not cover any technical measurements (you can find several of them available, just put the lens name + review in some search engine), but rather impressions about how it performed in daily use. So let's take a closer look.


Out of the box; build quality.


In the box you can find the lens, massive lens hood, metal tripod stand (detachable), high quality lens bag, gaps and manual. The design is classic Tamron-like with lots of gold and some blue/white colors used. Body is of the high quality despite its plastic housing (some users are complaining the build quality feels cheap compared with their L glass - not a problem for me during using the lens some weeks (or a couple of thousand of shots)). So the lens looks/feels as good as you could dream, considering the price tag.






It's a full frame lens, so you can use with your film body if you'd like, or with your latest digital FX body. Works also nicely with DX/aps-c, which improves the actual macro performance even better (it is 1:1 with the full frame, so the at the closest focus distance you can have 36x24mm at your full resolution).


Tamron has decorated the lens with three "technical notes", AF (Auto Focus), SP (Super Performance) and Di (Digital Integration). There's also IF marked at the producer's home page, Tamron interprets the well known pair of letters of having the lens responsible of focusing being inside the body (more information (click IF at the page)).


SP - Super Performance - stands for the best Tamron can produce (both optical and build quality), Di stands for lens coating for digital cameras (many older lenses had problems with the reflections caused by the closest lens for the sensor). As of today, the newest Tamron lens are marked with Di II, lens built especially for aps-c sized sensors.


As it is a fixed lens, the majority of the external design is just the focus ring. There's also the SEC ring (allows filter to be turned by simply turning the filter thread), also the manual aperture ring when desired to use the aperture manually (latest digital backs are eager to remind you to lock the aperture ring at minimum though).


Tamron claims this lens to be F:3.5 constant aperture, but the actual maximum aperture value varies from the farthest/infinity focus being 1/3.5 to the closest focus being 1/5.6. (I could not find confirmation to this from any review, how ever I was able to use the lens in two Nikons (D40x, D90), and both bodies acted the same, so there was no possibility to use the maximum aperture at the closest focusing distance.






Lens in use. Optical Quality.


Once you mount the lens in your camera, the look and feel is that this is something serious, and anyone staying next to you can see you smiling like a stupid fool. So is there a reason to smile on, when it comes to actual shooting?


Majority of the information I had before trying the lens, was 90% of the users claiming the glass to be just superior. This is something I can only confirm - the lens is very sharp, even at its widest aperture. Majority of the lens, especially fixed focus lens, with quite a bright aperture, are often able to perform at its best when stopped down a step or two. So a typical scenario at this case would be to stop down a 1:1.4 lens to 1:2.8 and there's the excellent performance you considered to be usable.


Fortunately this is not the scenario with the Tamron 180mm F:3.5 It's very sharp already at wide open and I believe users are appreciating slower lens performing with excellence at its widest, than faster (and therefore more expensive and heavy) lens performing poorly at its widest aperture.










At a very intensive testing at various conditions I found the F:6.3 to be the sweet spot of the lens; this could differ from one copy to another (in my case F:6.3 always gave excellent results). The glass also tolerates shooting agains light quite well, not paying too much interest to contrast or lens flare.


This the 100% view of the previous picture (Aperture F:5.6, ISO400): the subject distance is near to the closest possible:






As you can see, the lens perfectly represents the paradox of physics - the closer the focus (the larger the detail), the higher the interest to be paid, to the quality of the picture. Specifically as we have macro lens here, we have to consider the following at very close focus distances (especially at 1:1):


- extremely thin depth of field (tricky to select the desired focus point; note that at the given picture, the desired focus point could be the eye, not the center of his head)
- optical distortions, including chromatic aberration and sensitivity for taking the picture against the light source (lens flare, poor contrast of image).
- potential to have the image blurred despite the decent shutter speed (as a rule of thumb, a generally "good" shutter speed could be 1/focal lenght, so 1/180s with this lens, or even 1/270 when we are using DX sensor)


There are also other aspects like if the subjects was not moving and if your hands were steady, so considering all of the above, theres a lot of potential that you do not get a good shot rather than that you get sharp, well focused, well exposed shot. In many cases, it was almost impossible to get anything good without stabling the lens (especially when shooting small animals, like this one here (he was about 12mm long).


The lens also works great as a tele photo lens, however this was not the main subject of the testing this time. An example of non-macro shot as follows, together with the 100% crop to give the idea of the actual sharpness:


















The aperture value is F:4.5, shutter speed 1/180, ISO200. The subject distance is around 2 meters. (You can also download the pictures and take a look at the actual EXIF if you need full specs of the picture).


Finally, here's an example of how the lens performs with the subject being almost at infinite focus (F/5.6, 1/400, ISO400):
















Bokeh.


The bokeh is a nice word (originally in Japanese - means "to blur") understood by photographers as how pleasing is the out of focus area of the image, for the eyes. The "good" bokeh should be "smooth and buttery" while the "bad" could be "too sharp, hurting the eyes, jagged, with CA" and in a word, anything you'd like the nice out of focus image to look like. The majority of how good the bokeh is, depends on how high quality glass is used. So the high quality lens should have "high quality bokeh". (I'm using quotation marks here because the subject of the nature of bokeh is always arguable - some of like it in one way, some another way).


The bokeh also depends on what kind of (rounded or straight), and how many, diaphragm blades are used. This basically "draws" the shape of the contrasty areas of the bokeh, with rounded (newer) blades in general to be smoother than the straight ones. The number of blades can also help, for example a bokeh with 8 blades of diaphragm can look better than one with 6 blades; so bokeh created with 8 rounded blades can look considerably better than with six straight blades. You can find enormous amount of articles about bokeh around, if you care to browse the web.


Finally, the bokeh depends on what's there at the background and how close is the focus of the subject (so "how far away" is everything else).


Despite having 7 blades only, the bokeh of Tamron 180mm F:3.5 Macro is just marvellous. The long focal course and close focus guarantees you that anything you'll have in the background will appear smooth and buttery, as one good bokeh should be.


Thanks to its thin depth of field and superb bokeh, this lens is also quite usable as a portrait lens, and if you'd like to take pictures of someone where the differentiation from the background is important. The characteristics of the wide open (F:3.5) is quite similar to Nikon's 70-200mm/2.8 VR(I) lens; comparing how the lens look side by side, there coating also looks quite similar, so who knows maybe there's some connection between them ;)




Focus and Auto Focus.


This is the part of the lens review I'd like to skip - the auto focus of this lens is just not usable for me. The only scenario the auto focus would be useful, is to track a subject with a capable camera (DX/FX Pro line, D300x, D700, D3* in Nikon's model selection), or when your subject is moving very little at a given focus distance (for example if you are shooting objects farther than 5-6m).


This is a dedicated macro lens so the AF is built to focus closer subjects first. This means that if your subject is out of focus, the camera first screws the focus to the closest focus point (takes about 3,5 seconds with D90 body), and then starts to screw the focus back to infinity, where your subject could be. This means 7-8 seconds waiting time! A new prime minister can take over the work of the existing one, not talking of small flying objects flying around, any other wildlife you'd like to capture. The AF decides to choose the infinity direction of focus ONLY when the camera clearly understands that the subject is at the farther than the current focus, not closer. So with all that said, the screwed AF can really screw you, no matter the direction; so totally unusable in majority of situations you can think of in macro world.


Fortunately the view through the prism viewfinder is bright and clear, so you can, at any time, focus the subject manually without any hassle. It seems the Tamron engineers are also aware of that, and kudos to them, as the manual focus really works smoothly with this lens, and I had no problem to have any subject focused precisely in manual mode.


The auto focus, as it is screw based one, is also quite loud, so no AF-mode in silent nature (I would not mind the loudness otherwise, if I had the AF working quickly and smoothly).


With all that said, once the auto focus snaps the subject, it is very accurate; and if the subject is not moving too fast, it can easily track the subject through the majority of the focus range.






Drawbacks.


While the performance of the optical side of this lens is simply excellent, there's also a couple of details I'd like to see at the next model of this lovely lens.


- First of all, the auto focus. The USM/SWM type of auto-focus would be not only great, but absolutely a must!
- Focus limiter(s). With a lens with such a loooong focal course, there should be at least 2 limiters: 1) from 1m to infinity; from 1m to the closest focus. Preferably even 3: inf-1,5, 1,5-0,75, 0,75-0,47 (Closest). This would allow the user to use autofocus 99% of the time efficiently and smoothly (at the moment, user might want to use MF 99% of the time).
- Full time manual focus override. A standard solution for majority of professional lenses these days, this option would always be appreciated (no matter the capabilities and intelligence of the modern AF-s, human eye is always faster and more precise)
- Vibration Control - VC (This is the term Tamron likes to use, Nikons have VR, Canons have IS). It would definitely be quite helpful to have a lens with such a long focal length stabilized, so there's some serious advantage with not that good (light) conditions to shoot. Even one stop advantage would be just great (Tamron is currently offering the 1st generation of their vibration control system; while the engineers of Nikon and Canon can already have the VR/IS1 at their left hand the VR/IS2 and their right hand claiming "this one worked well, but this one works even better")
- Weather sealing. Shooting serious macro does not only mean a walk in the park. So many of the photographers would appreciate if they could take pictures at a light rain or not so common conditions. (The worse the (weather) conditions to take the picture, the better the chance to get a really great picture).


I do not personally miss the all-metal body. It would add unnecessary weigh and I'm not a type of user using the lens as a table stand or a clawhammer. The contradiction here is, that the weather sealed body often refers to a metal constructed lens. So go get it, perhaps the engineers have something to think about, here.






Bottom Line.


In a word, what I really liked:


- the build quality of the lens. A pleasure to use in a wide variety of conditions.
- the performance of the optics. Clear, contrasty and sharp pictures.
- the lovely bokeh
- the awesome manual focus ring


I did not enjoy the following:


- auto focus unusable at majority of shooting situations
- the lack of lens stabilization
- the lack of focus limiter(s)
- the lack of full time manual focus override
- the lack of weather sealed body


Majority of the time I was using the lens (about 2 weeks, around 3000 shots), I was using it in aperture priority and manual mode 50/50, with manual focus and auto focus at 99/1 ratio. So this is my personal experience how the lens worked in real use. Considering the price tag (around €700 in EU) you get some stunning glass for your money. But I'm sure many would like to pay much less for the useless AF; at the same time, many would love to pay extra to have the for all the current drawbacks listed above.


The better the mixture, the better the picture. The Tamron 180mm lens is a nice mixture of high quality glass, well built body and smooth manual focus. The glass is always #1, so you can enjoy your 180mm Tamron at the fullest if you know what you are dealing with.






I had no problem with buying a beer to the engineer responsible of the optical quality of this great lens. But to have the glass better, and even more with everything listed at the "Drawbacks".. this would be one hell of a party. Considering the current model is already some 8 years old, I'm quite sure we'll see this lens (even with better glass) with all the bells and whistles very very soon.


You can also take a closer look at the 8 photos posted just previously, all of them are shot with the same, 180mm Tamron lens.

Like a Fly on a Wall



(Lens: Tamron 180mm F:3.5 Macro 1:1)

Floating



(Lens: Tamron 180mm F:3.5 Macro 1:1)

Silky



(Lens: Tamron 180mm F:3.5 Macro 1:1)

H2O



(Lens: Tamron 180mm F:3.5 Macro 1:1)

Painting



(Lens: Tamron 180mm F:3.5 Macro 1:1)

Hidden



(Lens: Tamron 180mm F:3.5 Macro 1:1)

Wednesday, October 26, 2011

Tuesday, October 25, 2011

Danseur Noble



"Think you're the only one able to scratch your back with your leg? Think again."
(Lens: Tamron 180mm F:3,5 Macro 1:1)

The Monastery.
